Form Factor

M.2

Capacity

250GB, 500GB, 1TB

Sequential Read Speed

Up to 3,500 MB/s

Sequential Write Speed

Up to 3,000 MB/s

Model Code (Capacity)1)

MZ-V8V250BW (250GB)

MZ-V8V500BW (500GB)

MZ-V8V1T0BW (1TB)

General Feature

APPLICATION

Client PCs

FORM FACTOR

M.2 (2280)

INTERFACE

PCIe® Gen 3.0 x4, NVMe™ 1.4

DIMENSION (WxHxD)

80.15 x 22.15 x 2.38 (mm)

WEIGHT

Max 8.0 g

STORAGE MEMORY

Samsung V-NAND 3-bit MLC

CONTROLLER

Samsung In-House Controller

CACHE MEMORY

HMB(Host Memory Buffer)

Special Feature

TRIM SUPPORT

Supported

S.M.A.R.T SUPPORT

Supported

GC (GARBAGE COLLECTION)

Auto Garbage Collection Algorithm

ENCRYPTION SUPPORT

AES 256-bit Encryption (Class 0)

TCG/Opal IEEE1667 (Encrypted drive)

WWN SUPPORT

Not Supported

DEVICE SLEEP MODE SUPPORT

Yes

Performance2)

SEQUENTIAL READ

250GB: Up to 2,900 MB/s

500GB: Up to 3,100 MB/s

1TB: Up to 3,500 MB/s

SEQUENTIAL WRITE

250GB: Up to 1,300 MB/s

500GB: Up to 2,600 MB/s

1TB: Up to 3,000 MB/s

RANDOM READ (4KB, QD32)

250GB: Up to 230,000 IOPS

500GB: Up to 400,000 IOPS

1TB: Up to 500,000 IOPS

RANDOM WRITE (4KB, QD32)

250GB: Up to 320,000 IOPS

500GB: Up to 470,000 IOPS

1TB: Up to 480,000 IOPS

RANDOM READ (4KB, QD1)

250GB: Up to 17,000 IOPS

500GB: Up to 17,000 IOPS

1TB: Up to 17,000 IOPS

RANDOM WRITE (4KB, QD1)

250GB: Up to 53,000 IOPS

500GB: Up to 54,000 IOPS

1TB: Up to 54,000 IOPS

Environment

AVERAGE POWER CONSUMPTION

(SYSTEM LEVEL)3)

250GB: Average 3.7 W Maximum 5.6 W (Burst mode)

500GB: Average 4.3 W Maximum 5.9 W (Burst mode)

1TB: Average 4.6 W Maximum 5.3 W (Burst mode)

POWER CONSUMPTION (IDLE)3)

Max. 45 mW

POWER CONSUMPTION (DEVICE SLEEP)

Max. 5 mW

ALLOWABLE VOLTAGE

3.3 V ± 5 % Allowable voltage

RELIABILITY (MTBF)

1.5 Million Hours Reliability

OPERATING TEMPERATURE

0 - 70 ℃

SHOCK

1,500 G & 0.5 ms (Half sine)

Accessories

INSTALLATION KIT

Not Available

Software

INSTALLATION KIT

Magician Software for SSD management

Warranty

MZ-V8V250BW (250GB)

5 Years or 150 TBW

MZ-V8V500BW (500GB)

5 Years or 300 TBW

MZ-V8V1T0BW (1TB)

5 Years or 600 TBW
