UTP 8Port Switch UTP3-GSW0802-TSP120 8×PoE Ports 1×RJ45 Port 1xSFP Port CCTV SWITCH SINGAPORE POE Switch Repair NEW

CHOICECYCLE CCTV offers UTP 8Port Switch UTP3-GSW0802-TSP120 8×PoE Ports 1×RJ45 Port 1xSFP Port CCTV SWITCH SINGAPORE POE Switch Repair NEW.

The UTEPO 8-Port PoE Switch UTP3-GSW0802-TSP120 is a network switch specifically designed for efficient and managed Power over Ethernet (PoE) operations. Here are its features and functions:

The 8 Ports Full Gigabit PoE Ethernet Switch (UTP3-GSW0802-TSP120) is an unmanaged Ethernet switch designed to deliver high-speed Gigabit Ethernet access with Power over Ethernet (PoE) functionality. With eight PoE-enabled Gigabit downlink ports and one uplink Ethernet port, this switch is ideal for powering network devices like IP cameras, access points, and VoIP phones. Equipped with robust features and a compact design, it’s the perfect choice for a variety of applications such as security surveillance, SMB engineering, hotels, and schools.

Key Features:

• Full Gigabit Speed: All eight downlink ports support Gigabit Ethernet speeds (10/100/1000Base-T), ensuring fast data transmission across your network for high-performance applications like HD video surveillance.
• PoE Power Output: Each downlink port supports the IEEE 802.3af/at PoE standards, providing up to 30W per port with a total PoE budget of 120W. This allows you to power multiple devices directly through the Ethernet cable without needing additional power supplies.
• One-Key VLAN Function: With the one-key VLAN function, this switch isolates communication between downlink and uplink ports, enhancing network security and preventing data interference.
• SFP Slot for Uplink: In addition to the standard 1 Gigabit Ethernet uplink port, the switch features a 1000Base-X SFP port, enabling flexible and long-distance fiber optic connectivity for enhanced network scalability.
• Surge and ESD Immunity: Built with 6KV surge immunity and 6KV (contact discharge) / 8KV (air discharge) ESD immunity, this switch ensures reliable performance even in electrically noisy environments, providing stable and secure data transmission.
• Compact and Durable Design: With a sleek, durable design and a lightweight build (500g), this switch can easily be integrated into various installations, whether in tight spaces or large network racks.

UTP 8Port Switch UTP3-GSW0802-TSP120 8×PoE Ports 1×RJ45 Port 1xSFP Port CCTV SWITCH SINGAPORE POE Switch Repair NEW

Specifications:

• Model: UTP3-GSW0802-TSP120
• Downlink Ports: 8× 10/100/1000Base-T (PoE)
• Uplink Ports: 1× 10/100/1000Base-T Ethernet & 1× 1000Base-X SFP Port
• Switching Capacity: 20Gbps
• Packet Forwarding Rate: 14Mpps
• Forwarding Modes: Store and Forward
• PoE Power Output: 54V DC, 30W max per port
• PoE Budget: 120W max total
• Surge Immunity: 6KV (IEC61000-4-5)
• ESD Immunity: 6KV (contact discharge), 8KV (air discharge) (IEC61000-4-2)
• Input Voltage: DC 48V~57V
• Power Consumption: <5W
• Operating Temperature: -10°C ~ 45°C
• Storage Temperature: -40°C ~ 85°C
• Humidity: 5% ~ 95% (non-condensing)
• Dimensions: 200mm × 101.8mm × 27mm
• Weight: 500g
• Certification: CE, FCC, ROHS

Applications:

• Security Surveillance: Perfect for surveillance systems that require reliable PoE power for IP cameras.
• Hotels, Schools, and SMBs: Suitable for small to medium-sized businesses, educational institutions, and hospitality environments needing stable network connections and device power.
• Ethernet and Fiber Network Integration: Flexible integration with both Ethernet and fiber-optic uplinks.

In the Box:

• 8 Ports Full Gigabit PoE Ethernet Switch (1 unit)
• Power Adapter (1 unit)
• Accessory (1 unit)
• User Manual (1 unit)

---

Why Choose the UTP3-GSW0802-TSP120 PoE Ethernet Switch?

The 8 Ports Full Gigabit PoE Ethernet Switch (UTP3-GSW0802-TSP120) is designed to meet the increasing demands of high-performance networks. Whether you need to power IP cameras for security surveillance or support PoE-enabled devices across your office or campus, this switch offers a seamless, cost-effective solution. With robust power delivery, high-speed Gigabit Ethernet, and advanced surge and ESD protections, this PoE switch provides the reliability and efficiency you need to ensure your network runs smoothly.

---

Contact Information

Store Location:
SGCCTV Choicecycle, Sim Lim Square CCTV Specialist #02-81

Operating Hours:
11 AM – 8 PM

WhatsApp:
+65 98534404 (for stock inquiries before visiting)

Email:
enquiry@choicecycle.com.sg

Website:
https://sgcctv.com.sg

---

Conclusion

The 8 Ports Full Gigabit PoE Ethernet Switch (UTP3-GSW0802-TSP120) is the perfect choice for organizations seeking a reliable, high-performance solution for PoE applications. Whether for security surveillance or general networking, this switch offers powerful PoE capabilities, high-speed connectivity, and robust protection features—all in a compact, durable form. Enhance your network infrastructure today with this reliable, efficient, and cost-effective PoE Ethernet switch.
