MODEL NUMBER

MCS-S600-KN5N-S00 (Steel), MCS-S600-KG5N-S00 (TG)

SERIES

Silencio Series

SIZE

Mid Tower

AVAILABLE COLOR(S)

Black

MATERIALS

Steel, Plastic, Tempered Glass, Sound Dampening Material

DIMENSIONS (L X W X H)

478mm x 209mm x 470.5mm (incl. Protrusions), 466mm x 209mm x 460.5mm (excl. Protrusions)

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX

EXPANSION SLOTS

7

5.25" DRIVE BAYS

1

3.5" DRIVE BAYS

4

2.5" DRIVE BAYS

5

I/O PANEL

2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Headset Jack (Audio+Mic), 1x SD card reader

PRE-INSTALLED FANS - FRONT

1x 120mm (PWM 800-1400 RPM)

PRE-INSTALLED FANS - REAR

1x 120mm (PWM 800-1400 RPM)

FAN SUPPORT - FRONT

2x 120/140mm

FAN SUPPORT - TOP

2x 120/140mm

FAN SUPPORT - REAR

1x 120mm

RADIATOR SUPPORT - FRONT

120mm, 140mm, 240mm, 280mm

RADIATOR SUPPORT - TOP

120mm / 240mm (remove ODD) (35mm max motherboard component height)

RADIATOR SUPPORT - REAR

120mm

CLEARANCE - CPU COOLER

TG: 166mm, Steel: 167mm

CLEARANCE - GFX

398mm

CLEARANCE - PSU

180mm

POWER SUPPLY SUPPORT

Bottom mount, ATX PS2

DUST FILTERS

Top, Front, Bottom

CABLE ROUTING

18-26mm
