MODEL
MPY-850V-AFBAG
ATX VERSION
ATX 12V V2.52
PFC
Active PFC
INPUT VOLTAGE
100-240V
INPUT CURRENT
13-6A
INPUT FREQUENCY
50-60Hz
DIMENSIONS (L X W X H)
160 x 150 x 86 mm
FAN SIZE
135mm
FAN BEARING
FDB
FAN SPEED
1545 RPM
NOISE LEVEL @ 20%
0 dBA
NOISE LEVEL @ 50%
15.4 dBA
NOISE LEVEL @ 100%
32.5 dBA
EFFICIENCY
90% @ Typical Load
80 PLUS RATING
80 PLUS Gold
ERP 2014 LOT 3
Yes
OPERATING TEMPERATURE
0-50°C
POWER GOOD SIGNAL
100 - 500 ms
HOLD UP TIME
17ms
MTBF
>100,000 Hours
PROTECTIONS
OVP, OPP, SCP, OCP, UVP, OTP
REGULATORY
CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
ATX 24-PIN CONNECTORS
1
EPS 4+4 PIN CONNECTORS
1
EPS 8 PIN CONNECTOR
1
SATA CONNECTORS
12
PERIPHERAL 4-PIN CONNECTORS
4
PCI-E 6+2 PIN CONNECTORS
6
SERIES
V Gold Series
80 PLUS
Gold
MODULAR
Full Modular
WATTAGE
Above 750W
Seller SKU: | COOLER MASTER V850 GOLD |
---|---|
Origin: | Singapore |
Minimum order quantity: | 1 |
Date first listed on Sim Lim Square: | Jul 13, 2022 |
