Product Details

High workload rating

Delivering dependable performance to any storage environment, Ultrastar hard drives are designed with a workload rating1 up to 550TB per year, up to 10 times the rating for desktop drives. Ultrastar drives employ advanced technologies for enterprise-class reliability, power efficiency and performance.

Enterprise-class storage to rely on

With up to 2.5 million hours MTBF, Ultrastar hard drives deliver reliability and durability, are built for year operation (24x7x365) within the most demanding storage environments and are backed with a 5-year limited warranty.

HelioSeal Technology

Featured in over 30 million Western Digital hard drives shipped, HelioSeal technology (on 10TB drives and above) allows for higher capacities and less turbulence on large storage arrays. And now on its 5th generation design, HelioSeal technology is field-tested and proven to deliver high capacity, reliability, and power efficiency you can trust.

Vibration Protection

Enhanced Rotational Vibration Safeguard (RVS) technology uses sophisticated electronics to monitor the drive and correct linear and rotational vibrations in real-time for improved performance versus traditional desktop drive in high vibration environments.

Dual-stage Actuator Technology

Ultrastar drives feature a dual-stage actuator head positioning system for a high degree of accuracy. The primary stage provides course displacement while the secondary stage uses piezoelectric motion to fine-tune the head positioning to a higher degree of precision.

Built on a proven design, part of a complete portfolio

The Ultrastar SATA Series is a subset of a broad line-up of Ultrastar data center hard drives. The complete portfolio offers SAS and SATA models and a variety of data encryption options.

Full Specifications

Capacity

1 TB

Form Factor

3.5 Inch

Cache Size

128 MB

Interface

SATA

Connector

SATA

Disk Speed (RPM)

7200rpm

Compatibility

Windows, Windows Server, Linux, and Mac OS.

In The Box

• 3.5" Western Digital Ultrastar SATA 6/GB/s hard drive

• Mounting Screws

Technical Details:
