SPECIFICATIONS

Model LANCOOL II MESH PERFORMANCE

Dimensions (D) 478mm x (W) 229mm x (H) 494mm

Motherboard E-ATX(width: under 280mm)/ATX/M-ATX/ITX

PSU 210mm

Color black

Materials

Steel

4.0mm tempered glass (both sides)

Fan Support Front: 2 x 140mm or 3 x 120mm

Top: 2 x 120mm or 2 x 140mm

Top of PSU chamber: 2 x 120mm

Radiator Front (multi-way fan/radiator bracket): 1 x 360/280/240mmTop: 1 x 240mm (aligned to the left)

VGA Length 384mm

CPU Clearance 176mm

Drive

Behind MB Tray: 2 x 2.5″ SSDBehind the right flip panel: 2 x 2.5”SSD

Hard Drive Cage: 3 x 3.5″ HDD/2.5″ SSD

Above PSU Chamber: 2 x 2.5″ SSD

Slot 7

I/O Ports

1 x Fan speed control button1 x TRRS AUDIO

2 x USB 3.0

1 x USB 3.1 TYPEC

Dust Filters 1 x Top (magnetic), 1 x Bottom (tray)

Incl Fans 2 x 140mm PWM Fan (front)

Rated Speed:600 ±200 (30% Duty)-1200RPM ±10%

Air Flow:60.56CFM

Noise:25.8dB(A)1x 120mm PWM fan (rear)

Rated Speed:600 ±200 (30% Duty)-1500RPM ±10%

Air Flow:54.6CFM

Noise:26.1dB(A)

Technical Details:
