Philips S Line monitor gives essential features for daily productivity and work comfortably. Virtually frameless with crisp FHD for an expended and clear view. EasyRead and Eye comfort with TUV certified to reduce eye fatigue.
Technical Specifications
Picture/Display
LCD panel type
IPS technology
Backlight type
W-LED system
Panel Size
23.8 inch / 60.5 cm
Display Screen Coating
Anti-Glare, 3H, Haze 25%
Effective viewing area
527.04 (H) x 296.46 (V)
Aspect ratio
16:9
Maximum resolution
1920 x 1080 @ 75 Hz*
Pixel Density
93 PPI
Response time (typical)
4 ms (Gray to Gray)*
Brightness
250 cd/m²
Contrast ratio (typical)
1000:1
SmartContrast
50,000,000:1
Pixel pitch
0.2745 x 0.2745 mm
Viewing angle
178º (H) / 178º (V)
@ C/R > 10
Picture enhancement
SmartImage
Color gamut (typical)
NTSC 91%*, sRGB 107%*
Display colors
16.7M
Scanning Frequency
30 - 85 kHz (H) / 48 - 75 Hz (V)
sRGB
Yes
Flicker-free
Yes
LowBlue Mode
Yes
EasyRead
Yes
Adaptive sync
Yes
Connectivity
Signal Input
VGA (Analog )
DVI-D (digital, HDCP)
DisplayPort 1.2
HDMI 1.4
HDCP
HDCP 1.4 (DVI/DP/HDMI)
Sync Input
Separate Sync
Sync on Green
Audio (In/Out)
PC audio-in
Headphone out
Convenience
Built-in Speakers
2 W x 2
User convenience
SmartImage
Input
Brightness
Menu
Power On/Off
Control software
SmartControl
OSD Languages
Brazil Portuguese
Czech
Dutch
English
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukranian
Other convenience
Kensington lock
VESA mount (100x100mm)
Plug & Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7
Stand
Height adjustment
130 mm
Pivot
-/+ 90 degree
Swivel
-/+ 180 degree
Tilt
-5 ~ 25 degree
Power
ECO mode
10.4 W (typ.)
On mode
13.6 W (typ.) (EnergyStar test method)
Standby mode
0.3 W (typ.)
Off mode
0.3 W (typ.)
Power LED indicator
Operation - White
Standby mode- White (blinking)
Power supply
Built-in
100-240VAC, 50-60Hz
Dimensions
Product with stand(max height)
540 x 482 x 205 mm
Product without stand (mm)
540 x 323 x 51 mm
Packaging in mm (WxHxD)
625 x 435 x 180 mm
Weight
Product with stand (kg)
4.83 kg
Product without stand (kg)
2.98 kg
Product with packaging (kg)
7.91 kg
Operating conditions
Temperature range (operation)
0°C to 40°C °C
Temperature range (storage)
-20°C to 60°C °C
Relative humidity
20%-80 %
Altitude
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
MTBF (demonstrated)
70,000 hrs (excluded backlight)
Sustainability
Environmental and energy
EnergyStar 8.0
EPEAT*
TCO Certified
RoHS
Recyclable packaging material
100 %
Post consumer recycled plastic
85%
Specific Substances
PVC / BFR free housing
Mercury free
Compliance and standards
Regulatory Approvals
CB
EPA
FCC Class B
ICES-003
CE Mark
TUV/GS
TUV Ergo
SEMKO
CU-EAC
TUV Eye Comfort certified
PSB
Cabinet
Front bezel
Black
Rear cover
Black
Foot
Black
Finish
Texture
Brand: | Philips Monitors |
---|---|
Model number: | 242S1AE |
UPC: | 8712581773038 |
Seller SKU: | Philips 23.8" Business Monitor UPC: 8712581773038 Model number: 242S1AE |
Origin: | Singapore |
Minimum order quantity: | 1 |
Shipping weight: | 7910.00 g |
Date first listed on Sim Lim Square: | Dec 23, 2021 |
