Standards Wi-Fi 6

IEEE 802.11ax/ac/n/a 5 GHz

IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds AX6600

5 GHz: 4804 Mbps (802.11ax, HE160)

5 GHz: 1201 Mbps (802.11ax)

2.4 GHz: 574 Mbps (802.11ax)

WiFi Range 4-6+ Bedroom Houses (2-pack)

TP-Link Mesh Technology

Optional Ethernet backhaul work together to link Deco units to provide seamless coverage

AI-Driven Mesh

Intelligently learns the network environment to provide ideal Wi-Fi unique to your home

4× High-Gain Antennas (Internal)

Multiple antennas form a signal-boosting array to cover more directions and large areas

2× Smart Antennas (Internal)

Smart antennas auto-detect other Deco units to establish a stronger backhaul between one another to boost WiFi coverage

Tri-Band

Provides an extra 5 GHz band working exclusively as the strong backhaul, strengthening the WiFi coverage

Beamforming

Concentrates wireless signal strength towards clients to expand WiFi range

WiFi Capacity Very High

Tri-Band

Distribute devices to different bands for optimal performance

4×4 MU-MIMO

Simultaneously communicates with multiple MU-MIMO clients

OFDMA

Simultaneously communicates with multiple WiFi 6 clients

8 Streams

More than enough bandwidth for connected devices

Working Modes Router Mode

Access Point Mode

HARDWARE

Processor 1.5 GHz Quad-Core CPU

Ethernet Ports 1× 2.5 Gbps Port

1× Gigabit Port

*Per Deco Unit

Supports WAN/LAN auto-sensing

Buttons Reset Button

Power 12 V ⎓ 2.5 A

SECURITY

WiFi Encryption WPA-Personal

WPA2-Personal

WPA3-Personal

Network Security SPI Firewall

Access Control

HomeShield Security

Real-Time IoT Protection

Malicious Site Blocker

Intrusion Prevention System

DDoS Attack Prevention

Home Network Scanner

Guest Network 1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

SOFTWARE

Protocols IPv4

IPv6

Service Kits HomeShield

Learn More>

Parental Controls HomeShield Parental Controls

Custom Profiles

Professional Content Filter Library

Family Time

Bedtime

Off Time

Time Rewards

Family Online Time Ranking

Pause the Internet

Weekly and Monthly Reports

WAN Types Dynamic IP

Static IP

PPPoE

PPTP

L2TP

Quality of Service HomeShield QoS

QoS by Application

Cloud Service OTA Firmware Upgrade

TP-Link ID

DDNS

NAT Forwarding Port Forwarding

UPnP

IPTV IGMP Proxy

IGMP Snooping

Bridge

Tag VLAN

DHCP Address Reservation

DHCP Client List

Server

DDNS TP-Link

Management Deco App

PHYSICAL

Dimensions (W×D×H) 5.1 × 4.8 × 8.3 in

(130 × 123 × 210 mm)

Package Contents Deco X90 (2-pack)

2 Deco X90 Units

1 RJ45 Ethernet Cable

2 Power Adapters

1 Quick Installation Guide

System Requirements Android 4.4 or later

iOS 9.0 or later

Certifications CE, EAC, FCC, IC, RoHS, RCM

Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

TEST DATA

WiFi Transmission Power CE:

<20 dBm (2.4 GHz)

<30 dBm (5 GHz)

FCC:

<30 dBm (2.4 GHz)

<30 dBm (5 GHz)

Technical Details:
