SPECIFICATIONS
Model Name 22B1HS
Panel Size 21.5" / 546mm
Pixel Pitch (mm) 0.24795 (H) × 0.24795 (V)
Effective Viewing Area (mm) 476.064 (H) × 267.786 (V)
Brightness (typical) 250 cd/m²
Contrast Ratio 1000 : 1 (typical) 20 Million : 1 (DCR)
Response 7ms (GtG(BW))
Viewing Angle 178° (H) / 178° (V) (CR > 10)
Color Gamut NTSC 76.8% (CIE1976) / sRGB 91.1% (CIE1931)
Optimum Resolution 1920 × 1080 @ 60Hz
Display Colors 16.7 Million
Signal Input VGA, HDMI 1.4
Power Supply 19VDC, 1.31A
Smart Power Mode (typical) 21W
Built-in Speakers no
Regulatory Approvals BSMI / RCM / MEPS / CE / CB / FCC
Wall-Mount 75mm × 75mm
Cabinet Color Black
Adjustable Stand Tilt: -4° ~ 21.5°
Product with Stand (mm) 391.9 (H) × 490.1 (W) × 180.8 (D)
Packaging (mm) 456 (H) × 556 (W) × 120 (D)
Weight (Net / Gross) kg 2.16 / 2.8
Brand: | AOC |
---|---|
Model number: | 22B1HS |
UPC: | 4717385944794 |
Seller SKU: | AOC 21.5" Monitor UPC: 4717385944794 Model number: 22B1HS |
Origin: | Singapore |
Minimum order quantity: | 1 |
Shipping weight: | 2800.00 g |
Date first listed on Sim Lim Square: | Dec 23, 2021 |
SPECIFICATIONS
Model Name 22B1HS
Panel Size 21.5" / 546mm
Pixel Pitch (mm) 0.24795 (H) × 0.24795 (V)
Effective Viewing Area (mm) 476.064 (H) × 267.786 (V)
Brightness (typical) 250 cd/m²
Contrast Ratio 1000 : 1 (typical) 20 Million : 1 (DCR)
Response 7ms (GtG(BW))
Viewing Angle 178° (H) / 178° (V) (CR > 10)
Color Gamut NTSC 76.8% (CIE1976) / sRGB 91.1% (CIE1931)
Optimum Resolution 1920 × 1080 @ 60Hz
Display Colors 16.7 Million
Signal Input VGA, HDMI 1.4
Power Supply 19VDC, 1.31A
Smart Power Mode (typical) 21W
Built-in Speakers no
Regulatory Approvals BSMI / RCM / MEPS / CE / CB / FCC
Wall-Mount 75mm × 75mm
Cabinet Color Black
Adjustable Stand Tilt: -4° ~ 21.5°
Product with Stand (mm) 391.9 (H) × 490.1 (W) × 180.8 (D)
Packaging (mm) 456 (H) × 556 (W) × 120 (D)
Weight (Net / Gross) kg 2.16 / 2.8
