Output

Max Configurable Power (Watts)

780 Watts / 1.3kVA

Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Sync to mains

Topology

Line interactive

Input

Input frequency

50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations

176 - 294V

Batteries & Runtime

Battery type

Lead-acid battery

Typical recharge time

16hour(s)

Replacement Battery

APCRBC165

Expected Battery Life (years)

3 - 5

RBC Quantity

1

Battery Charge Power (Watts)

11 Watts

Interface Port(s)

USB

Control panel

Multifunction LCD status and control console

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge energy rating

509Joules

Data Line Protection

RJ45 10/100/1000 Base-T Ethernet protection

Filtering

Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous

Physical

Maximum Height

100MM, 10.0CM

Maximum Width

250MM, 25.0CM

Maximum Depth

382MM, 38.2CM

Net Weight

10.2KG

Shipping weight

11.85KG

Shipping Height

330MM, 33.0CM

Shipping Width

485MM, 48.5CM

Shipping Depth

225MM, 22.5CM

Color

Black

Master Carton Dimensions (Length x Width x Height)

356 x 51 x 254MM

Master Carton Units

1.0

Master Carton Weight

12.7

SCC Codes

10731304346903

Environmental

Operating Temperature

0 - 40 °C

Operating Relative Humidity

0 - 95 (Non-condensing) %

Operating Elevation

0 - 3048meters

Storage Temperature

-15 - 45 °C

Storage Relative Humidity

0 - 95 (Non-condensing) %

Storage Elevation

0 - 15240meters

Audible noise at 1 meter from surface of unit

45.0dBA

Online thermal dissipation

22.0BTU/hr
