Computer Connections4Port SelectionHotkey, Pushbutton
ConnectorsConsole Ports2 x USB Type A Female (rear panel) 1 x HDMI Female (Black) 2 x 3.5 mm Audio Jack Female (Green; 1 x front, 1 x rear) 2 x 3.5 mm Audio Jack Female (Pink; 1 x front, 1 x rear)KVM Ports4 x USB Type B Female 4 x HDMI Female (Black) 4 x 3.5 mm Audio Jack Female (Green) 4 x 3.5 mm Audio Jack Female (Pink)Firmware Upgrade1 x 3.5 mm Audio Jack Female (Black)Power1 x DC JackUSB Hub2 x USB Type A Female (1 x front panel; 1 x rear panel)
SwitchesSelected5 x Pushbutton
LEDsAudio5 (Green)KVM5 (Orange)USB5 (Green)
EmulationKeyboard / MouseUSBVideo1920 x 1080 @ 60Hz / 1920 x 1200 @ 60HzScan Interval1-99 seconds (default: 5 sec.)Power ConsumptionDC5.3V:3.62W:43BTU
EnvironmentalOperating Temperature0-50°CStorage Temperature-20-60°CHumidity0-80% RH, Non-condensing
Physical PropertiesHousingMetal, PlasticWeight0.53 kg ( 1.17 lb )Dimensions (L x W x H)26.23 x 7.68 x 4.40 cm (10.33 x 3.02 x 1.73 in.)NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
Brand: | ATEN |
---|---|
Model number: | CS1794 |
Seller SKU: | CS1794 |
Origin: | Singapore |
Minimum order quantity: | 1 |
Date first listed on Sim Lim Square: | Nov 15, 2021 |
Computer Connections4Port SelectionHotkey, Pushbutton
ConnectorsConsole Ports2 x USB Type A Female (rear panel) 1 x HDMI Female (Black) 2 x 3.5 mm Audio Jack Female (Green; 1 x front, 1 x rear) 2 x 3.5 mm Audio Jack Female (Pink; 1 x front, 1 x rear)KVM Ports4 x USB Type B Female 4 x HDMI Female (Black) 4 x 3.5 mm Audio Jack Female (Green) 4 x 3.5 mm Audio Jack Female (Pink)Firmware Upgrade1 x 3.5 mm Audio Jack Female (Black)Power1 x DC JackUSB Hub2 x USB Type A Female (1 x front panel; 1 x rear panel)
SwitchesSelected5 x Pushbutton
LEDsAudio5 (Green)KVM5 (Orange)USB5 (Green)
EmulationKeyboard / MouseUSBVideo1920 x 1080 @ 60Hz / 1920 x 1200 @ 60HzScan Interval1-99 seconds (default: 5 sec.)Power ConsumptionDC5.3V:3.62W:43BTU
EnvironmentalOperating Temperature0-50°CStorage Temperature-20-60°CHumidity0-80% RH, Non-condensing
Physical PropertiesHousingMetal, PlasticWeight0.53 kg ( 1.17 lb )Dimensions (L x W x H)26.23 x 7.68 x 4.40 cm (10.33 x 3.02 x 1.73 in.)NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
No reviews
