SPECIFICATIONS

PRIME-GX-1000

Technical Specifications

80PLUS® Gold

Cybenetics Efficiency Level TBA

Cybenetics Noise Level TBA

Form Factor Intel ATX 12 V

Dimensions 170 mm (L) x 150 mm (W) x 86 mm (H)

Fan Information Fan Size 135 mm

Fan Control Premium Hybrid Fan Control

Fan Bearing Fluid Dynamic Bearing

Life Expectancy 50,000 hours at 40 °C, 15 % - 65 % RH

Cable Information Modularity Fully Modular

Cable type Flat black cables

Electrical Features Operating Temperature 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)

MTBF @ 25 °C, excl. fan 150,000 hours

AC Input Full Range

Protection OPP, OVP, UVP, OCP, OTP, SCP

Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE

Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Warranty 12 Years

Power Output

AC Input Voltage: 100 V - 240 V

Current: 13 - 6.5 A

Frequency: 50 Hz - 60 Hz

DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB

Maximum Power 25 A 25 A 83 A 0.3 A 3 A

125 W 996 W 3.6 W 15 W

Total continuous power 1000 W

CABLES

PRIME-GX-1000

Cable type Connector(s) per cable Total Length (mm) Number(s) of cable(s) included

MB-610 MB (24/20 pins) 1 610 1

CPU-650 CPU (8/4 pins) 1 650 2

PCIe-750-2x PCIe (8/6 pins) 2 750 0

PCIe-750-1x PCIe (8/6 pins) 1 750 6

SATA-810-4x-90 SATA 4 810 2

SATA-800-4x-180 SATA 4 860 1

SATA-760-4x-90 SATA 4 760 0

SATA-700-2x-90 SATA 2 700 0

SATA-570-2x-180 SATA 2 570 0

SATA-470-2x-180 SATA 2 470 0

SATA-450-2x-180 SATA 2 450 1

Molex-690-3x Molex 3 690 1

Molex-470-2x Molex 2 470 1

Molex-to-SATA-3-3-300 Molex to SATA 3.3 Adapter 2 300 1

Molex-to-FDD-101 Molex to FDD Adapter 1 101 0

Specifications are subject to change without prior notice.
