Choicecycle CCTV offer the best Solar Power CCTV Camera DS-2CD3T23G1-I/4G 4G Sim Card battery backup for Construction Entertainment Monitoring Police Investigation.

Hikvision DS-2CD3T23G1-I/4G

It can be used in the areas that are not suitable for laying wired network and electric supply lines, or used for the scenes that

feature tough environment and have high demanding for device stability. It can be used for monitoring the farms, electric

power cables, water and river system, oil pipelines and key forest areas. It also can be used in the temporary monitoring

scenes, such as the large-scale competitions, the sudden public activity, the temporary traffic control and the city

construction.

 High quality imaging with 2 MP resolution

 Clear imaging against strong back light due to 120 dB true

WDR technology

 LTE-TDD/LTE-FDD/WCDMA/GSM 4G wireless network

transmission, support Micro SIM card

 Camera: Water and dust resistant (IP67)

1. Collection from SGCCTV   Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 98534404 for stock level before visit.

2. Payment by PayNow 201207820G

SGCCTV Facebook https://www.facebook.com/sgcctv.com.sg

SGCCTV Twitter https://twitter.com/choicecycle1

SGCCTV Google Map https://goo.gl/maps/yoUGzrvqgSP5WcXD9  https://goo.gl/maps/bihTFoNeqCMsV2MJ8

SGCCTV Ecommerce https://sgcctv.com.sg/

SGCCTV Project Reference https://sgcctv.biz/

SGCCTV Maintenance  https://choicecycle.com.sg/

Camera

Image Sensor 1/2.8" Progressive Scan CMOS

Max. Resolution 1920 × 1080

Min. Illumination Color: 0.004 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR

Shutter Time 1 s to 1/100,000 s

Day & Night IR cut filter

Lens

Lens Type Fixed focal lens, 2.8, 4, and 8 mm optional

Focal Length & FOV

2.8 mm, Horizontal FOV: 107°, vertical FOV: 57°, diagonal FOV: 128°

4 mm, Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°

8 mm, Horizontal FOV: 41°, vertical FOV: 22°, diagonal FOV: 47°

Lens Mount M12

Aperture

F1.4 (2.8 mm and 4 mm models support),

F1.6 (8 mm model supports)

DORI

DORI

2.8 mm: D: 44 m, O: 17.5 m, R: 9 m, I: 4.5 m

4 mm: D: 53 m, O: 21 m, R: 11 m, I: 5 m

8 mm: D: 110 m, O: 44 m, R: 22 m, I: 11 m

Illuminator

Supplement Light Type IR

Supplement Light Range Up to 30 m

IR Wavelength 850 nm

Smart Supplement Light Yes

Video

Main Stream

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

50Hz: 25fps (704 × 576, 640 × 480)

60Hz: 30fps (704 × 480, 640 × 480)

Third Stream

50Hz: 1fps (1280 × 720, 640 × 480)

60Hz: 1fps (1280 × 720, 640 × 480)

Video Compression

Main stream: H.265+/H.265/H.264+/ H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264

Video Bit Rate 32 Kbps to 8 Mbps

H.264 Type Baseline Profile, Main Profile, High Profile

H.265 Type Main Profile

Bit Rate Control CBR, VBR

Scalable Video Coding (SVC) H.264 and H.265 encoding

Region of Interest (ROI) 4 fixed regions for each stream

Target Cropping Yes

Network

Simultaneous Live View Up to 6 channels

API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP,

SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

User/Host

Up to 32 users

3 user levels: administrator, operator, and user

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication

(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest

authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network

Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, TLS 1.2

Network Storage

NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and health

detection are supported.

Client iVMS-4200, Hik-Connect, Hik-Central

Web Browser

Plug-in required live view: IE8+,

Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+,

Local service: Chrome 41.0+, Firefox 30.0+

Mobile Communication

Frequency

LTE-TDD: Band38/40/41；

LTE-FDD: Band1/3/5/7/8/20/28；

WCDMA: Band1/5/8

GSM: Band3/5/8

Standard LTE-TDD, LTE-FDD, WCDMA, GSM


Wide Dynamic Range (WDR) 120 dB

Day/Night Switch Day, Night, Auto, Schedule

Picture Overlay LOGO picture can be overlaid on video with 128 × 128 24bit bmp format.

Image Enhancement BLC, HLC, 3D DNR, Defog

Image Parameters Switch Yes

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance,

adjustable by client software or web browser

SNR ≥ 52 dB

Privacy Mask 4 programmable polygon privacy masks

Interface

RS-485 1 RS-485 (Half duplex)

On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

Reset Key Yes

Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

Basic Event Motion detection, video tampering alarm, exception

Smart Event

Line crossing detection, intrusion detection, region entrance detection, region exiting

detection, unattended baggage detection, object removal detection, scene change

detection,

*The smart events are only supported in full power mode.

Linkage

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger

recording, trigger capture

General

Power 12 VDC ± 25%, 0.33 A, max. 4 W

Web Client Language

33 languages

English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,

French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,

Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,

Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding

Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating

Conditions

-15 °C to 55 °C (-15 °F to 5 °F). Humidity 95% or less (non-condensing)

Material Cover: Metal, main body: Plastic

Dimension 219 mm × 114.3 mm × 109.3 mm (8.62" × 4.5" × 4.3")

Package Dimension 826 mm × 469 mm × 444 mm (32.5" × 18.5" × 17.5")

Weight Approx. 1, 070 g (2.36 lb.)

With Package Weight Approx. 1, 900 g (4.18 lb.)

Approval

EMC

CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011

+A1: 2014,

RCM: AS/NZS CISPR 32: 2015

RF

CE-RED: EN 301489-1 V2.2.3; EN 301489-52 V1.1.0; EN 62311:2008,

ICASA: EN 301 489-1 V2.2.3; EN 301 489-52 V1.1.0;EN 62311:2008

Safety

CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013;

IEC 62368-1:2014, CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013;

EN 62368-1:2014+A11:2017

Environment

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

Protection IP67: IEC 60529-2013
