Output
Max Configurable Power (Watts)
325 Watts / 625VA
Efficiency at Full Load
65.3 %
Output Frequency (sync to mains)
50/60 Hz +/- 1 Hz Unsynchronised
Topology
Line interactive
Waveform type
Square wave
Transfer Time
4 ms typical : 8 ms maximum
Input
Input frequency
45 - 65 Hz
Input voltage range for main operations
151 - 299V
Number of Power Cords
1
Efficiency at Full Load
65.3 %
Type of Input Protection Required
3-pole circuit breaker
Batteries & Runtime
Battery type
Lead-acid battery
Included Battery Modules
1
Typical recharge time
6hour(s)
Replacement Battery
APCRBC110
Expected Battery Life (years)
2 - 4
Battery Charge Power (Watts)
11 Watts
Physical
Maximum Height
279MM, 27.85CM
Maximum Width
160MM, 16.0CM
Maximum Depth
89MM, 8.85CM
Net Weight
5.0KG
Shipping weight
5.2KG
Shipping Height
399MM, 39.9CM
Shipping Width
215MM, 21.5CM
Shipping Depth
128MM, 12.8CM
Color
Black
Master Carton Units
1.0
Units per Pallet
100.0
SCC Codes
10731304308178
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 %
Storage Temperature
-15 - 40 °C
Audible noise at 1 meter from surface of unit
45.0dBA
Seller SKU: | BX625CI |
---|---|
Origin: | Singapore |
Minimum order quantity: | 1 |
Date first listed on Sim Lim Square: | Jul 13, 2022 |
