Operating System

Windows 10 Home

Windows 10 Pro

Windows 11 Home

Free Upgrade to Windows 11¹ (when available, see below); Barebone and Non-OS SKUs are excluded

CPU

AMD Ryzen™ 5 5500U Processor 2.1GHz (11M Cache, up to 4.0GHz); (Barebone SKU)

AMD Ryzen™ 7 5700U Processor 1.8GHz (12M Cache, up to 4.3GHz); (Barebone SKU)

AMD Ryzen™ 3 5300U Processor 2.6GHz (6M Cache, up to 3.8GHz); (Barebone SKU)

AMD Ryzen™ 3 5300U Processor 2.6GHz (6M Cache, up to 3.8GHz)

AMD Ryzen™ 5 5500U Processor 2.1GHz (11M Cache, up to 4.0GHz)

AMD Ryzen™ 7 5700U Processor 1.8GHz (12M Cache, up to 4.3GHz)

Chipset

TPM module on board

Integrated

Graphics

Integrated - Radeon™ Vega Graphics

Memory

8GB DDR4 Memory

16GB DDR4 Memory

8GB DDR4 Memory x 2

16GB DDR4 Memory x 2

4GB DDR4 Memory

Storage

512GB M.2 NVMe™ PCIe® 3.0 SSD

1TB M.2 NVMe™ PCIe® 3.0 SSD

1TB SATA 7200RPM 2.5" HDD

128GB M.2 NVMe™ PCIe® 3.0 SSD

256GB M.2 NVMe™ PCIe® 3.0 SSD

Wireless Data Network

Wi-Fi 6, Bluetooth 5.0, 2*2 (Barebone SKU)

Wi-Fi 5, Bluetooth 4.0, 2*2 (Barebone SKU)

Wi-Fi 5, Bluetooth 4.2, 2*2

Wi-Fi 6, Bluetooth 5.0, 2*2

w/o Wi-Fi

LAN

10/100/1000 Mbps

2.5G LAN, Realtek® RTL8125B-CG

Gigabit LAN, Realtek® 8111EP

Audio

Realtek® ALC3251 or ALC3236-VB2 HD Audio CODEC (optional)

Side(Front) I/O Ports

1 x USB 3.2 Gen2 Type-C(w/ quick charge, DP output), 1 x USB3.2 Gen1 Type-A, 1x 4-in-1 Card Reader, 1 x Consumer Infrared Sensor, 2 x Microphone Array, 1x Audio Jack(optional), 1 x K-Lock(side)

Back I/O Ports

1 x HDMI, 1 x USB 3.2 Gen2 Type-C(w/ DP output), 1 x Configurable Port (option: VGA/COM/DP/LAN), 2 x USB 3.2 Gen1 Type-A, 1 x RJ45 LAN, 1 x DC-in

Configurable I/O

1 x Display1.4 Port (Barebone SKU)

1 x Display1.2 Port (Barebone SKU)

1 x VGA Port (Barebone SKU)

1 x Display1.2 Port

1 x VGA Port

1 x Display1.4 Port

1 x COM Port

1 x Lan(RJ-45) Port (Barebone SKU)

Speaker

No

Power Supply

19Vdc, 3.42A, 65W Power Adapter

19Vdc, 4.74A, 90W Power Adapter

Dimensions (W x D x H)

115 x 115 x 49 mm

Weight

700g (include 2.5" HDD)

Color

Black

White

Accessories

WIRELESS KBM

DP to VGA Cable

USB Keyboard & Mouse

Certificates

BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI

Remark

¹The Windows 11 upgrade will be delivered to qualifying devices late 2021 into 2022. Timing will vary by device. Certain features require specific hardware (see aka.ms/windows11-spec).
