Hardware Specifications

CPU

CPU Model Intel Celeron N5105

CPU Architecture x64 64-bit

CPU Frequency Quad-Core 2.0GHz (burst up 2.90 GHz)

Memory

Memory 8GB SO-DIMM DDR4

Memory Module Pre-installed 8GB (1x 8GB)

Total Memory Slots 2

Memory Expandable up to 16GB (2x 8GB)

Support mixed capacity

Flash Memory 8GB eMMC

Storage

Drive Bays 6

M.2 Drive Slots 4

Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

M.2 2280 NVMe

Maximum Drive Bays with Expansion Unit 14

External Ports

Expansion 2x USB 3.2 Gen 2x1

Network 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)

PCIe Expansion Slots 1x for optional expansion 10 GbE card

HDMI Output 1x HDMI 2.0b

Others

System Fan 1x 120mm

LCD Panel

Infrared Receiver

Power Supply Unit / Adapter 250W x1

Input Power Voltage 100V to 240V AC

Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA

Warranty 3 Years

Operation

Power Consumption 48.5 W (Operation);

27.7 W (Disk Hibernation);

0.81 W (Sleep Mode)

Noise Level 18.1dB (HDD idle)

Operation Temperature 0°C~40°C (32°F~104°F)

Humidity 5% to 95% RH

Size and Weight

Size 185.5 (H) x 233 (W) x 230 (D) mm

Weight 4.87 kg / 10.74 lb
