Hardware Specifications

CPU

CPU Model Intel Celeron J4125

CPU Architecture x64 64-bit

CPU Frequency Quad-Core 2.0GHz (burst up 2.70 GHz)

Memory

Memory 4GB SO-DIMM DDR4

Memory Module Pre-installed 4GB (1 x 4GB)

Total Memory Slots 2

Memory Expandable up to 8GB (2 x 4GB)

Support mixed capacity

Flash Memory 8GB eMMC

Storage

HDD 4 x SATA3 6Gb/s; 3.5"/2.5" HDD/SSD

M.2 Drive Slots 2x M.2 PCIe (NVMe)

*M.2 2280 (PCIe Gen2 )

Maximum Internal Raw Capacity 72 TB (18 TB HDD X 4, Capacity may vary by RAID types)

Maximum Drive Bays with Expansion Unit 16

Maximum Raw Capacity with Expansion Units 288 TB (18 TB HDD X 16, Capacity may vary by RAID types)

External Ports

Expansion USB 3.2 Gen 1 x3

Network 2.5 Gigabit Ethernet x 2 (2.5G/1G/100M)

HDMI Output HDMI 2.0a x1

Others

System Fan 120mm x 1

LCD Panel

Infrared Receiver

Power Supply Unit / Adapter 90W x1

Input Power Voltage 100V to 240V AC

Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC

Operation

Power Consumption 27.6 W (Operation);

12.6 W (Disk Hibernation);

0.75 W (Sleep Mode)

Noise Level 17.6dB (HDD idle)

Operation Temperature 0°C~40°C (32°F~104°F)

Humidity 5% to 95% RH

Size and Weight

Size 185.5(H) x 170(W) x 230(D) mm

Weight 2.96 kg / 6.52 lb
