MODEL NUMBER

MB540-KGNN-S00

SERIES

MasterBox Series

SIZE

Mid Tower

AVAILABLE COLOR(S)

Black

MATERIALS

Steel, Mesh, Plastic, Tempered Glass

DIMENSIONS (L X W X H)

499.3 x 208.6 x 498mm (incl. Protrusions), 488.3 x 208.6 x 498mm (excl. Protrusions)

VOLUME (EXLC. PROTRUSIONS)

51.87L

MOTHERBOARD SUPPORT

Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12” x 10.7” motherboards, may impact cable management feature)

EXPANSION SLOTS

7

5.25" DRIVE BAYS

0

2.5" / 3.5" DRIVE BAYS (COMBO)

2

2.5" DRIVE BAYS

4

I/O PANEL

2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button

PRE-INSTALLED FANS - TOP

N/A

PRE-INSTALLED FANS - FRONT

N/A

PRE-INSTALLED FANS - REAR

1x 120mm 650~1800RPM SickleFlow PWM ARGB

FAN SUPPORT - TOP

3x 120mm, 2x 140mm

FAN SUPPORT - FRONT

3x 120mm, 2x 140mm

FAN SUPPORT - REAR

1x 120mm

RADIATOR SUPPORT - TOP

120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)

RADIATOR SUPPORT - FRONT

120mm, 140mm, 240mm, 280mm, 360mm

RADIATOR SUPPORT - REAR

120mm

CLEARANCE - CPU COOLER

165mm/6.49"

CLEARANCE - PSU

180mm/7.08", 295mm/11.61" (w/ HDD cage removed)

CLEARANCE - GFX

410mm/16.1"

DUST FILTERS

Top, Front, Bottom

POWER SUPPLY SUPPORT

ATX
