Specifications
3.5"/2.5" Universal drive mounts
2 included
Dedicated 2.5" drive mounts
2 included, 4 positions total
Expansion slots
7
Front interface (RGB version)
2x USB 3.0, Audio I/O, Power button, RGB controller, USB type-C ready
Front interface (Standard version)
2x USB 3.0, Audio I/O, Power button, Reset button, USB type-C ready
Total fan mounts
9x 120/140 mm
Front fan (RGB version)
3x 120/140 mm (3x Aspect 14 RGB included)
Front fan (Standard version)
3x 120/140 mm (2x Aspect 14 included)
Top fan
3x 120/140 mm
Rear fan (RGB version)
1x 120/140 mm (1x Aspect 14 RGB included)
Rear fan (Standard version)
1x 120/140 mm (1x Aspect 14 included)
Bottom fan
2x 120/140 mm
Dust filters
Top and bottom (mesh front)
Fixed velcro straps
Yes
Cable routing grommets
Yes
Captive thumbscrews
HDD, SSD and PSU brackets
Left side panel
Tempered glass
Right side panel
Steel
Compatibility
Motherboard compatibility
E-ATX (max 285 mm)/ ATX / mATX / Mini-ITX
Power supply type
ATX
PSU max length
250 mm (with HDD cage installed)
GPU max length (RGB version)
450 mm
GPU max length (Standard version)
451 mm (476 mm without front fan)
CPU cooler max height
185 mm
Front radiator
Up to 360/280 mm
Top radiator
Up to 360 mm
Rear radiator
120 mm
Bottom radiator (RGB version)
Up to 240 mm
Bottom radiator (Standard version)
Up to 280 mm
Cable routing space
30 mm
Dimensions
Case dimensions (LxWxH)
542 x 240 x 474 mm
Case dimensions w/o feet/protrusions/screws
541 x 240 x 454 mm
Package dimensions (LxWxH)
540 x 330 x 640 mm
Net weight
9.6 kg
Gross weight
11.2 kg
Volume
59 liters
Other
Warranty
2 Years
Package contents
Meshify 2 Lite Case, User manual, Small accessory box
EAN
Black TG Light Tint: 7340172703877, White TG Clear Tint: 7340172703884, RGB Black TG Light Tint: 7340172703891
UPC
Black TG Light Tint: 843276103873, White TG Clear Tint: 843276103880, RGB Black TG Light Tint: 843276103897
JAN
Black TG Light Tint: 4537694296878, White TG Clear Tint: 4537694296885, RGB Black TG Light Tint: 4537694296892
Product code
Black TG Light Tint: FD-C-MEL2A-03, White TG Clear Tint: FD-C-MEL2A-04, RGB Black TG Light Tint: FD-C-MEL2A-05
Seller SKU: | Fractal Design Meshify 2 Lite ATX(argb black) |
---|---|
Origin: | Singapore |
Minimum order quantity: | 1 |
Date first listed on Sim Lim Square: | Aug 5, 2022 |
Specifications
3.5"/2.5" Universal drive mounts
2 included
Dedicated 2.5" drive mounts
2 included, 4 positions total
Expansion slots
7
Front interface (RGB version)
2x USB 3.0, Audio I/O, Power button, RGB controller, USB type-C ready
Front interface (Standard version)
2x USB 3.0, Audio I/O, Power button, Reset button, USB type-C ready
Total fan mounts
9x 120/140 mm
Front fan (RGB version)
3x 120/140 mm (3x Aspect 14 RGB included)
Front fan (Standard version)
3x 120/140 mm (2x Aspect 14 included)
Top fan
3x 120/140 mm
Rear fan (RGB version)
1x 120/140 mm (1x Aspect 14 RGB included)
Rear fan (Standard version)
1x 120/140 mm (1x Aspect 14 included)
Bottom fan
2x 120/140 mm
Dust filters
Top and bottom (mesh front)
Fixed velcro straps
Yes
Cable routing grommets
Yes
Captive thumbscrews
HDD, SSD and PSU brackets
Left side panel
Tempered glass
Right side panel
Steel
Compatibility
Motherboard compatibility
E-ATX (max 285 mm)/ ATX / mATX / Mini-ITX
Power supply type
ATX
PSU max length
250 mm (with HDD cage installed)
GPU max length (RGB version)
450 mm
GPU max length (Standard version)
451 mm (476 mm without front fan)
CPU cooler max height
185 mm
Front radiator
Up to 360/280 mm
Top radiator
Up to 360 mm
Rear radiator
120 mm
Bottom radiator (RGB version)
Up to 240 mm
Bottom radiator (Standard version)
Up to 280 mm
Cable routing space
30 mm
Dimensions
Case dimensions (LxWxH)
542 x 240 x 474 mm
Case dimensions w/o feet/protrusions/screws
541 x 240 x 454 mm
Package dimensions (LxWxH)
540 x 330 x 640 mm
Net weight
9.6 kg
Gross weight
11.2 kg
Volume
59 liters
Other
Warranty
2 Years
Package contents
Meshify 2 Lite Case, User manual, Small accessory box
EAN
Black TG Light Tint: 7340172703877, White TG Clear Tint: 7340172703884, RGB Black TG Light Tint: 7340172703891
UPC
Black TG Light Tint: 843276103873, White TG Clear Tint: 843276103880, RGB Black TG Light Tint: 843276103897
JAN
Black TG Light Tint: 4537694296878, White TG Clear Tint: 4537694296885, RGB Black TG Light Tint: 4537694296892
Product code
Black TG Light Tint: FD-C-MEL2A-03, White TG Clear Tint: FD-C-MEL2A-04, RGB Black TG Light Tint: FD-C-MEL2A-05
