EAP773 BE11000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

Overview

The EAP773 is an Ultra-Thin Enterprise Wi-Fi 7 Access Point designed to deliver BE11000 Tri-Band Wi-Fi 7 speeds with advanced technologies for businesses requiring high-speed, low-latency, and interference-free wireless connectivity. With its elegant ceiling-mount design, 10G PoE++ port, and Omada Cloud SDN support, the EAP773 is an ideal choice for modern enterprise networks in offices, retail spaces, hotels, and educational institutions.

Key Features

• Wi-Fi 7 BE11000 Speeds: 5760 Mbps (6 GHz) + 4320 Mbps (5 GHz) + 574 Mbps (2.4 GHz) for ultra-fast, lag-free connectivity.†
• Tri-Band Wi-Fi: Ensures optimized network traffic and minimal interference with dedicated frequency bands.
• 10G PoE++ Port: Unlocks the full potential of Wi-Fi 7 with ultra-fast wired backhaul and flexible deployment.
• 320 MHz Bandwidth: Supports ultra-wide channels for increased data throughput and improved network efficiency.‡
• Multi-Link Operation (MLO): Simultaneously transmits data across multiple frequency bands and channels, reducing latency and improving network stability.‡
• Auto Channel Selection & Power Adjustment: Enhances wireless performance while reducing interference.
• AI-Driven Optimization: Features Omada Mesh and AI Roaming for seamless wireless connectivity and expansion.△
• Advanced Security: Includes WPA3 encryption, captive portal authentication, rogue AP detection, and guest network support with up to 24 SSIDs.
• Centralized Cloud Management: Manage the network locally or remotely via Omada Cloud SDN.
• Ultra-Thin Design: Stylish, compact form factor measuring Φ220 mm × 32.5 mm, ideal for ceiling installations.

Technical Specifications

• Wi-Fi Standard: Wi-Fi 7 (802.11be), backward compatible with Wi-Fi 6/6E/5/4
• Frequency Bands:

  • 6 GHz: Up to 5760 Mbps
  • 5 GHz: Up to 4320 Mbps
  • 2.4 GHz: Up to 574 Mbps
• Ethernet Port: 1× 10G PoE++ Port (802.3bt)
• Security Features:

  • WPA3, WPA2-Enterprise
  • Captive portal authentication (SMS & Voucher login)△
  • Rogue AP detection
  • Up to 24 SSIDs for segmented network access
• Antenna Type: Internal high-gain antennas
• Management:

  • Omada Cloud SDN (Zero-Touch Provisioning, Intelligent Monitoring)
  • Auto Channel Selection & Power Adjustment
  • Mesh and AI Roaming△
• Dimensions: Φ220 mm × 32.5 mm
• Mounting: Ceiling-mount, ultra-thin design
• Power Supply: PoE++ (802.3bt)

Why Choose the EAP773?

• Enterprise-Grade Wi-Fi 7: Deliver next-generation speeds and enhanced reliability with Multi-Link Operation and 320 MHz Bandwidth.
• Optimized for High-Density Environments: Supports high-bandwidth applications such as cloud computing, HD video conferencing, and remote offices.
• Future-Proof Design: Features 4096-QAM, multi-RUs, and 10-bit symbol modulation for increased traffic capacity.
• Scalable & Centralized Management: Seamlessly integrates into Omada SDN for cloud-based or on-premises management.
• Enhanced Security & Guest Access: Protects business networks with WPA3 encryption, captive portal login, and rogue AP detection.
• Sleek, Space-Saving Design: Fits elegantly in offices, hotels, retail spaces, and educational institutions.

Omada Cloud SDN Integration

The EAP773 integrates seamlessly with Omada SDN, offering cloud-based network management with features such as:

• Zero-Touch Provisioning (ZTP) for effortless deployment.*
• Intelligent Monitoring to track network performance and security.
• Hybrid Cloud Management with hardware, software, or cloud-based controllers.
• AI-Powered Network Optimization for auto-adjusting channel settings and power levels.

Contact Us

For inquiries, product availability, or to place an order, contact us at:

Store Location:
SGCCTV Choicecycle, Sim Lim Square CCTV Specialist #02-81

Operating Hours:
11 AM – 8 PM

WhatsApp:
+65 98534404 (for stock inquiries before visiting)

Email:
enquiry@choicecycle.com.sg

Website:
https://sgcctv.com.sg

Conclusion

The EAP773 BE11000 Wi-Fi 7 Ceiling Mount Access Point is designed to redefine business networking with its ultra-fast tri-band speeds, AI-driven optimizations, enterprise-grade security, and centralized cloud management. Whether you're upgrading your office network, enhancing retail connectivity, or deploying high-performance wireless coverage in a large venue, the EAP773 is the ultimate solution for future-proof, high-capacity networking. Contact us today to learn more or place an order!

† Maximum wireless signal rates are theoretical values derived from IEEE Standard 802.11 specifications. Actual performance may vary based on environmental conditions and network factors.

‡ Wi-Fi 7 features such as 320 MHz bandwidth, Multi-Link Operation (MLO), and 4K-QAM require compatible client devices.

△ Omada Mesh, AI Roaming, Captive Portal, and Cloud Access require an Omada SDN controller for full functionality. Please check the Omada user guide for configuration details.

• Zero-Touch Provisioning requires the Omada Cloud-Based Controller (subscription required).
