Technical Specifications

Picture/Display

LCD panel type

IPS technology

Backlight type

W-LED system

Panel Size

27 inch / 68.6 cm

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Effective viewing area

596.736 (H) x 335.664 (V)

Aspect ratio

16:9

Maximum resolution

2560 x 1440 @ 75 Hz*

Pixel Density

109 PPI

Response time (typical)

4 ms (Gray to Gray)*

Brightness

300 cd/m²

Contrast ratio (typical)

1000:1

SmartContrast

50,000,000 :1

Pixel pitch

0.2331 x 0.2331 mm

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Flicker-free

Yes

Picture enhancement

SmartImage

Display colors

16.7 M

Color gamut (typical)

NTSC 110%*, sRGB 123%*

Scanning Frequency

30 - 114 kHz (H) / 48 - 75 Hz (V)

sRGB

Yes

LowBlue Mode

Yes

EasyRead

Yes

Adaptive sync

Yes

Connectivity

Signal Input

DisplayPort 1.4 x 1, HDM 1.4 x 2, USB-C 3.2 Gen 1 x 1 (upstream, power delivery up to 90 W)

HDCP

HDCP 1.4 (HDMI / DP / USB-C)

HBR3

for USB-C

Signal Output

DisplayPort out

USB:

USB-C x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)

Audio (In/Out)

Audio out

RJ45

Ethernet LAN up to 1G*, Wake on LAN

Sync Input

Separate Sync

USB

USB-C

Reversible plug connector

Super speed

Data and Video transfer

DP

Built-in Display Port Alt mode

Power delivery

USB PD version 3.0

USB-C max. power delivery

Up to 90W (5V/3A; 7V/3A; 9V/3A; 10V/3A; 12V/3A; 15V/3A; 20V/4.5A)

Convenience

Built-in Speakers

2 W x 2

User convenience

SmartImage

Input

PowerSensor

Menu

Power On/Off

Control software

SmartControl

OSD Languages

Brazil Portuguese

Czech

Dutch

English

French

Finnish

German

Greek

Hungarian

Italian

Japanese

Korean

Portuguese

Polish

Russian

Simplified Chinese

Spanish

Swedish

Traditional Chinese

Turkish

Ukranian

Other convenience

Kensington lock

VESA mount (100x100mm)

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 / 8.1 / 8 / 7

Stand

Height adjustment

150 mm

Pivot

-90/+90

Swivel

-180/+180 degree

Tilt

-5/35 degree

Power

ECO mode

16.4 W (typ.)

On mode

20.2 W (typ.) (EnergyStar test method)

Standby mode

0.3 W

Off mode

Zero watts with Zero switch

Power LED indicator

Operation - White

Standby mode- White (blinking)

Power supply

Built-in

100-240VAC, 50-60Hz

Dimensions

Product with stand(max height)

613 x 537 x 225 mm

Product without stand (mm)

613 x 366 x 54 mm

Packaging in mm (WxHxD)

730 x 471 x 193 mm

Weight

Product with stand (kg)

7.26 kg

Product without stand (kg)

5.47 kg

Product with packaging (kg)

9.94 kg

Operating conditions

Temperature range (operation)

0°C to 40°C °C

Temperature range (storage)

-20°C to 60°C °C

Relative humidity

20%-80 %

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF (demonstrated)

70,000 hrs (excluded backlight)

Sustainability

Environmental and energy

PowerSensor

LightSensor

EnergyStar 8.0

EPEAT*

TCO Certified Edge

RoHS

Recyclable packaging material

100 %

Post consumer recycled plastic

85%

Specific Substances

Mercury free

PVC / BFR free housing

Compliance and standards

Regulatory Approvals

cETLus
