Technical Specifications

Picture/Display

AMD FreeSync™ technology

Yes

LCD panel type

IPS technology

Backlight type

W-LED system

Panel Size

29 inch / 73.66 cm

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Effective viewing area

672.77 (H) x 283.82 (V) mm

Aspect ratio

21:9

Maximum resolution

2560 x 1080 @ 75 Hz*

Pixel Density

96 PPI

Response time (typical)

4 ms (Gray to Gray)*

MPRT

1 ms

Brightness

300 cd/m²

Contrast ratio (typical)

1000:1

SmartContrast

Mega Infinity DCR

Pixel pitch

0.2628 x 0.2628 mm

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Picture enhancement

SmartImage game

Color gamut (typical)

NTSC 110.1%*, sRGB 126.3%*

Display colors

16.7 M

Scanning Frequency

30 - 99 kHz (H) / 48 - 75 Hz (V)

sRGB

Yes

Flicker-free

Yes

LowBlue Mode

Yes

EasyRead

Yes

Connectivity

Signal Input

DisplayPort x 1

HDMI x 2

Sync Input

Separate Sync

Audio (In/Out)

Headphone out

Convenience

Built-in Speakers

3 W x 2

MultiView

PIP/PBP mode

2x devices

User convenience

Power On/Off

Menu

Volume

Input

SmartImage Game

OSD Languages

Brazil Portuguese

Czech

Dutch

English

Finnish

French

German

Greek

Hungarian

Italian

Japanese

Korean

Polish

Portuguese

Russian

Simplified Chinese

Spanish

Swedish

Traditional Chinese

Turkish

Ukranian

Other convenience

Kensington lock

VESA mount (100x100mm)

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 / 8.1 / 8 / 7

Stand

Height adjustment

100 mm

Tilt

-5/20 degree

Power

On mode

16.24 W (typ.) (EnergyStar test method)

Standby mode

0.5 W

Off mode

0.3 W

Power LED indicator

Operation - White

Standby mode- White (blinking)

Power supply

External

100-240VAC, 50-60Hz

Dimensions

Product with stand(max height)

689 x 438 x 234 mm

Product without stand (mm)

689 x 312 x 41 mm

Packaging in mm (WxHxD)

770 x 477 x 159 mm

Weight

Product with stand (kg)

5.28 kg

Product without stand (kg)

3.48 kg

Product with packaging (kg)

7.85 kg

Operating conditions

Temperature range (operation)

0 to 40 °C

Temperature range (storage)

-20 to 60 °C

Relative humidity

20%-80 %

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF

50,000 hrs (excluding backlight) hour(s)

Sustainability

Environmental and energy

EnergyStar 8.0

RoHS

Mercury Free

Recyclable packaging material

100 %

Compliance and standards

Regulatory Approvals

EPA

CB

PSB

CE Mark

Cabinet

Color

Black

Finish

Textured
