Picture/Display

LCD panel type

VA LCD

Backlight type

W-LED system

Panel Size

48.8 inch / 124 cm

Display Screen Coating

Anti-Glare, 2H, Haze 25%

Effective viewing area

1193.5 (H) x 335.7 (V) mm at a 1800R curvature*

Aspect ratio

32:9

Maximum resolution

5120 x 1440 @ 70 Hz*

Pixel Density

109 PPI

Response time (typical)

5 ms (Gray to Gray)*

Brightness

450 cd/m²

Contrast ratio (typical)

3000:1

SmartContrast

80,000,000:1

Pixel pitch

0.233 x 0.233 mm

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Flicker-free

Yes

Picture enhancement

SmartImage

Display colors

16.7 M

Color gamut (min.)

BT. 709 Coverage: 99.67%*, DCI-P3 Coverage: 94.62%*

Color gamut (typical)

NTSC 103%*, sRGB 121%*, Adobe RGB 91%*

HDR

DisplayHDR 400 certified (DP / HDMI)

Scanning Frequency

30 - 230 kHz (H) / 48 - 70 Hz (V); Adaptive sync (for HDMI/DP)

SmartUniformity

97 ~ 102%

Delta E

< 2

sRGB

Yes

LowBlue Mode

Yes

EasyRead

Yes

Adaptive sync

Yes

Connectivity

Signal Input

DisplayPort 1.4* x 1, HDMI 2.0 b x 2, USB-C 3.1 Gen 2 x 1 (upstream, power delivery up to 65 W)

HDCP

HDCP 2.2 (HDMI / DP / USB-C)

USB:

USB 3.1 x 1 (upstream), USB 3.1 x 3 (downstream with x 1 fast charge B.C 1.2)

Audio (In/Out)

Headphone out

RJ45

Ethernet LAN up to 1G*

Sync Input

Separate Sync

USB

USB-C

Reversible plug connector

Super speed

Data and Video transfer

DP

Built-in Display Port Alt mode

Power delivery

USB PD version 2.0

USB-C max. power delivery

Up to 65W (5V/3A; 9V/3A; 10V/3A;12V/3A; 15V/3A; 20V/3.25A)

Convenience

Built-in Speakers

5 W x 2

Built-in webcam

2.0 megapixel FHD camera with microphone and LED indictor (for Windows 10 Hello)

MultiView

PBP (2x devices)

User convenience

SmartImage

Input

User

Menu

Power On/Off

Control software

SmartControl

OSD Languages

Brazil Portuguese

Czech

Dutch

English

Finnish

French

German

Greek

Hungarian

Italian

Japanese

Korean

Polish

Portuguese

Russian

Simplified Chinese

Spanish

Swedish

Traditional Chinese

Turkish

Ukranian

Other convenience

Kensington lock

VESA mount (100x100mm)

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 / 8.1 / 8 / 7

Stand

Height adjustment

130 mm

Swivel

-/+ 20 degree

Tilt

-5~15 degree

Power

ECO mode

43.3 W (typ.)

On mode

41.25 W (typ.) (EnergyStar test method)

Standby mode

0.3 W (typ.)

Off mode

Zero watts with Zero switch

Power LED indicator

Operation - White

Standby mode- White (blinking)

Power supply

Built-in

100-240VAC, 50-60Hz

Dimensions

Product with stand(max height)

1194 x 568 x 303 mm

Product without stand (mm)

1194 x 369 x 156 mm

Packaging in mm (WxHxD)

1308 x 384 x 553 mm

Weight

Product with stand (kg)

15.30 kg

Product without stand (kg)

11.00 kg

Product with packaging (kg)

21.48 kg

Operating conditions

Temperature range (operation)

0°C to 40°C °C

Temperature range (storage)

-20°C to 60°C °C

Relative humidity

20%-80 %

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF (demonstrated)

70,000 hrs (excluded backlight)
