Power +12VDC, 1A
Wireless Networking IEEE802.15.4 Zigbee network compliant
RF Frequency Range 2.4GHz - 2.5GHz
Multi-Purpose Output Ports One custom 3.5mm 4-conductor jack (port 1)
Designed for RTI modules as well as industry-standard IR emitters
IR Output Ports Two, 3.5mm jack (ports 2 & 3)
Compatible with industry-standard IR emitters
IR Output Drive 100mA maximum (per port, adjustable)
Infrared Frequency Range 15 KHz - 460 KHz
Infrared Input Compatible with industry-standard repeaters and receivers
Relays Two, 5 amps @ 30VDC
Sense Inputs Two, 3-24VDC
RS232 Ports One, Bi-directional RJ45 Connections
Ethernet Port One, 10/100Base-T with PoE (Class 3)
USB Ports One, Programming
RAM Memory 64MB
Flash Memory 128MB
Mounting Wall-mount or free standing
Operating Temperature +32°F to +122°F (0°C to +50°C)
Operating Humidity 5% to 95% Non-condensing
Seller SKU: | O046 |
---|---|
Origin: | Singapore |
Minimum order quantity: | 1 |
Date first listed on Sim Lim Square: | Dec 29, 2021 |
Power +12VDC, 1A
Wireless Networking IEEE802.15.4 Zigbee network compliant
RF Frequency Range 2.4GHz - 2.5GHz
Multi-Purpose Output Ports One custom 3.5mm 4-conductor jack (port 1)
Designed for RTI modules as well as industry-standard IR emitters
IR Output Ports Two, 3.5mm jack (ports 2 & 3)
Compatible with industry-standard IR emitters
IR Output Drive 100mA maximum (per port, adjustable)
Infrared Frequency Range 15 KHz - 460 KHz
Infrared Input Compatible with industry-standard repeaters and receivers
Relays Two, 5 amps @ 30VDC
Sense Inputs Two, 3-24VDC
RS232 Ports One, Bi-directional RJ45 Connections
Ethernet Port One, 10/100Base-T with PoE (Class 3)
USB Ports One, Programming
RAM Memory 64MB
Flash Memory 128MB
Mounting Wall-mount or free standing
Operating Temperature +32°F to +122°F (0°C to +50°C)
Operating Humidity 5% to 95% Non-condensing
