Specifications

Riser card interface: PCI Express 3.0 x16

2.5″ SSD unit positions: 2 (height limitation 10.5mm)

Expansion slots: 2

Front ports: 2x USB 3.0, Audio in/out, Power button with LED (white)

Position: Can be placed both vertical and horizontal position

Total fan mounts: 2x 120 mm in graphics card chamber

Dust filters: 3 (CPU, GPU & PSU)

Compatibility

Power supply type: SFX (up to 130 mm long)*

Motherboard compatibility: Mini ITX

GPU max dimensions (LxHxD): 310x145x47 mm

CPU cooler max height: 56 mm

*NOTE: Node 202 is not compatible with Ion SFX-L

Dimensions

Case dimensions - Horizontal (WxHxD): 377 x 82 x 330 mm

PSU Compatibility: SFX PSUs up to 130 mm long

Case dimensions - Horizontal, with feet/protrusions/screws (WxHxD): 377 x 88 x 332 mm

Case dimensions - Vertical, with feet/protrusions/screws (WxHxD): 125 x 385 x 332 mm

Net weight: 3.5 kg

Package dimensions (WxHxD): 145 x 463 x 388 mm

Package weight: 4.0kg

Volume: 10.3 litres
