ULTRASTAR DC SA620 SFF-7 7.0MM SATA MLC RI-1.8DW/D 15NMISE
$792
Availability: In Stock
Condition: New
Shipping:
Quantity:
9 in stock
Total:
Will be calculated after you select all properties
Buy Now Enquiry
Bizgram Asia Pte Ltd
Address:
1 Rochor Canal Road #05-50 Sim Lim Square 188504
Singapore.
63341373
sales@bizgram.com
Add to Cart

400GB - 228$

800GB - 404$

1600GB - 792$

Model
BrandSanDisk
SeriesCloudSpeed Ultra Gen. II
ModelSDLF1DAM-400G-1HA1
Details
Form Factor 2.5"
Capacity400GB TO 1600GB
Memory Components MLC
InterfaceSATA III
Performance
Max Sequential ReadUp to 530 MBps
Max Sequential WriteUp to 460 MBps
4KB Random ReadUp to 76,000 IOPS
4KB Random WriteUp to 32,000 IOPS
MTBF 2,000,000 hours
Features
FeaturesCapacity offerings: 1.6TB, 800GB and 400GB

Optimized for mixed-use, latency-sensitive write operations

1.6TB version capable of 32,000 4K write IOPS; fewer servers to deliver I/O performance

QoS - average write latency at 56µ (microseconds)

Low power consumption compared to traditional HDDs

Data loss protection with power failure protection

Includes the innovative Guardian Technology Platform for improved flash endurance and data integrity/protection

MTBF = 2 Million hours

Cryptographically signed firmware

Works within existing infrastructure - 6Gb/s SATA interface
Environmental
Power Consumption (Idle)1.3W
Power Consumption (Active)3.8W average sequential write
2.6W average sequential read
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +95°C
Operating Humidity5% to 95% RH
Max Shock Resistance1000g @ 1.0 msec, 1 shock along each axis, X, Y, Z, in each direction
Max Vibration Resistance3.22 grms 5-1,000 Hz
Dimensions & Weight
Height7.17mm
Width69.85mm
Depth100.20mm
Additional Information
Date First AvailableJanuary 11, 2017MAIN OVERVIEW FEATURES:
  • Storage Capacity: 400 GB TO 1600 GB
  • Maximum Read Transfer Rate: 530 MB/s
  • Maximum Write Transfer Rate: 460 MB/s
  • Drive Interface: SATA
  • Drive Interface Standard: SATA/600
  • Drive Type: Internal
  • Drive Width: 2.5"
  • Device Supported: Server

Technical Details:

Seller SKU: SDLF1CRM-016T-1HA1
Origin: Singapore
Minimum order quantity: 1
Date first listed on Sim Lim Square: Mar 28, 2022

400GB - 228$

800GB - 404$

1600GB - 792$

Model
BrandSanDisk
SeriesCloudSpeed Ultra Gen. II
ModelSDLF1DAM-400G-1HA1
Details
Form Factor 2.5"
Capacity400GB TO 1600GB
Memory Components MLC
InterfaceSATA III
Performance
Max Sequential ReadUp to 530 MBps
Max Sequential WriteUp to 460 MBps
4KB Random ReadUp to 76,000 IOPS
4KB Random WriteUp to 32,000 IOPS
MTBF 2,000,000 hours
Features
FeaturesCapacity offerings: 1.6TB, 800GB and 400GB

Optimized for mixed-use, latency-sensitive write operations

1.6TB version capable of 32,000 4K write IOPS; fewer servers to deliver I/O performance

QoS - average write latency at 56µ (microseconds)

Low power consumption compared to traditional HDDs

Data loss protection with power failure protection

Includes the innovative Guardian Technology Platform for improved flash endurance and data integrity/protection

MTBF = 2 Million hours

Cryptographically signed firmware

Works within existing infrastructure - 6Gb/s SATA interface
Environmental
Power Consumption (Idle)1.3W
Power Consumption (Active)3.8W average sequential write
2.6W average sequential read
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +95°C
Operating Humidity5% to 95% RH
Max Shock Resistance1000g @ 1.0 msec, 1 shock along each axis, X, Y, Z, in each direction
Max Vibration Resistance3.22 grms 5-1,000 Hz
Dimensions & Weight
Height7.17mm
Width69.85mm
Depth100.20mm
Additional Information
Date First AvailableJanuary 11, 2017MAIN OVERVIEW FEATURES:
  • Storage Capacity: 400 GB TO 1600 GB
  • Maximum Read Transfer Rate: 530 MB/s
  • Maximum Write Transfer Rate: 460 MB/s
  • Drive Interface: SATA
  • Drive Interface Standard: SATA/600
  • Drive Type: Internal
  • Drive Width: 2.5"
  • Device Supported: Server
