Hardware Specifications

CPU

CPU Model Intel ATOM C3538

CPU Architecture x64 64-bit

CPU Frequency Quad-Core 2.1GHz

Memory

Memory 8GB SO-DIMM DDR4

Memory Module Pre-installed 8GB (1 x 8GB)

Total Memory Slots 2

Memory Expandable up to 64GB (2x 32GB)

Support mixed capacity

Flash Memory 4GB eMMC

Storage

Drive Bays 8

M.2 Drive Slots 2

Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

M.2 2280 NVMe

M.2 2280 SATA 3

M.2 2260 SATA 3

M.2 2242 SATA 3

Maximum Drive Bays with Expansion Unit 16

External Ports

Expansion USB 3.2 Gen 1 x 2

Network 10 Gigabit Ethernet x 2 (10G/1G);

2.5 Gigabit Ethernet x 2 (2.5G/1G/100M)

HDMI Output N/A

Others

System Fan 120mm x 2

LCD Panel

Power Supply Unit / Adapter 250W x1

Input Power Voltage 100V to 240V AC

Certification FCC, CE, VCCI, BSMI, C-TICK

Warranty 3 Years

Operation

Power Consumption 66.9W (Operation);

37.2W (Disk Hibernation);

Noise Level 22dB (HDD idle)

Operation Temperature 0°C~40°C (32°F~104°F)

Humidity 5% to 95% RH

Size and Weight

Size 215.5(H) x 293(W) x 230(D) mm

Weight 6.2 (kg) / 13.67 (lb)
